■ Excellent performance of high temperature-resistance, repeat steam ability in situation.
■ Hydrophobic membrane with high flow.
■ Low pressure drop, high flow rate, long service life
■ 100% integrity tested
■ Non fiber-releasing
■ FDA compliance material
■Dimensions: Outside diameter: 2.7" (69mm) Length: 9.75",10", 20", 30", 40"
■Material of Constructions:Filter media: PTFE Support/Drainage: PP Cage/Core/End cap: PP Seal Material : Silicone, EPDM, NBR, Viton, Teflon, E-FKM
■Removal Rating: For Gas:0.01µm, 0.02µm For Liquid: 0.1µm, 0.22µm, 0.45µm, 1µm
Maximum operating temperature: 80°C
Maximum operating pressure: 4.2bar @25°C
Maximum operating pressure(Reverse Direction): 2.0bar @25°C
Maximum temperature sterilization: 121°C every 30 minutes,30times
When filter the air, pressure is 2 bar ,start pressure 100Mbar ,10"filter can flow 300Nm³/h
