Nylon Pleated Filter Cartridge(FSNY serial)

PRODUCT > filter cartridge > Nylon Pleated Filter Cartridge(FSNY serial)

Nylon Pleated Filter Cartridge(FSNY serial)

The FSNY Series-N6 Pleated Filter Cartridge is constructed of Nylon6 media and nonwoven support materials. The adaptors arethermally welded without the use of glues or adhesive to prevent any possibility of pollution.

Price：￥0.00

■ Possessing better performance of high temperature-resistance, acid and base resistance

■ Hydrophilic membrane with high flow.

■ Non-fiber releasing according to pharmaceutics and food industry requirements

■ 100% integrity tested

■ Flushed with ultrapure water

■Dimensions: Outside diameter: 2.7" (69mm)　Length: 9.75",10", 20", 30", 40"

■Material of Constructions: Filter media: Nylon6 Support/Drainage: PP Cage/Core/End cap: PP Seal Material : Silicone, EPDM, NBR, Viton, Teflon, E-FKM

■Performance: Removal Rating: 0.1µm, 0.22µm, 0.45µm, 0.65µm, 1µm, 3µm, 5µm

　 Maximum operating temperature: 60°C

　 Maximum operating differential pressure: 4.2Bar@ 25°C

　 Maximum differential pressure (reverse direction): 2.1Bar@ 25°C

　 Maximum temperature sterilization: 30times, 30minutes at 121°C

■　Pharmaceutics ■　Food and beverage

■　Semiconductor
